1204EA-E44TA Industrial Diesel Engine

Industrial Diesel Engines 1204EA-E44TA

Request Consultation Find your Distributor

Key Specs

Maximum Power
148 HP
110 kW
Maximum Torque
413 lb-ft @ 1400 rpm
560 Nm @ 1400 rpm
China NR IV
China NR IV


The Perkins 1204, the 4 cylinder option for the 1200 Series, gives you a complete power solution that meets the latest China NR IV emission standards. The choice of options, engine configurations and robust technology allows you to integrate the 1204 range into your equipment with minimum re-engineering.
The innovative, compact and flexible design of the Perkins 1200 Series means it can be found in more than 800 different models of equipment.

Product Specifications for 1204EA-E44TA

Maximum Power 148 HP 110 kW
Maximum Torque 413 lb-ft @ 1400 rpm 560 Nm @ 1400 rpm
Rated Speed 2200 rpm 2200 rpm
Minimum Power 110 HP 82 kW
Emissions China NR IV China NR IV
Number of Cylinders 4 inline 4 inline
Cycle 4 stroke 4 stroke
Bore 4.1 in 105 mm
Stroke 5 in 127 mm
Displacement 268.5 in³ 4.4 l
Compression Ratio 16.5:1 16.5:1
Aspiration Turbocharged aftercooled Turbocharged aftercooled
Combustion System Direct injection Direct injection
Rotation from Flywheel End Anti-clockwise Anti-clockwise
Aftertreatment DOC+DPF DOC+DPF
Cooling System Liquid Liquid
Length 25 in 635 mm
Width 33.3 in 845 mm
Height 28.5 in 725 mm
Dry Weight 1076 lb 488 kg
Length 26.5 in 675 mm
Width 18.8 in 478 mm
Height 15.3 in 390 mm
Weight 99 lb 45 kg
Note 1 *Final dimensions dependent on selected options *Final dimensions dependent on selected options

1204EA-E44TA Standard Equipment

Air System

  • Standard air cleaners

Electrical and Electronics

  • Flexible and configurable software features and well-supported SAE J1939 CAN bus enables highly integrated machines
  • Full electronic control system, all connectors and wiring looms waterproof and designed to withstand harsh off-highway environments

Cooling System

  • 50:50 water glycol mix
  • Detailed guidance on cooling system design and validation available to ensure machine reliability
  • Top tank temperature 108°C (226°F) as standard to minimize cooling pack size

Flywheel and Flywheel Housing

  • Wide choice of drivetrain interfaces, including SAE No. 2 and SAE No. 3 configurations

Fuel System

  • Electronic high pressure common rail
  • Innovative filter design to ensure maximum protection of the engine


  • Available with or without a balancer

Oil System

  • Wide choice of sumps for different applications

Power Take-Off (PTO)

  • SAE A and SAE B flanges on left-hand side. Additional SAE A flange available on left-hand side. Engine power can also be taken from the front of the engine on some applications. Factory fitted compressors are also available.

See how 1204EA-E44TA compares against frequently compared products.
