1100 Series
From the 3 cylinder 1103 range to the 6 cylinder 1106 range, this is a series of engines that gives unparalleled performance. The engines have exceptional reliability and low cost of ownership. Their trusted performance is borne out of thousands of hours of validation in the real world, working with agricultural, construction and electric power providers who value our reputation and expertise. Electric power engines in the series achieve regulated and unregulated emission standards globally. Within the 1100 Series of industrial engines are mechanical and electronic units up to Stage IIIA/Tier 3 equivalent emissions standards.
Perkins® 1100 Series engine range
Industrial engines
Industrial open power units
Electric power engines - certified
Electric power engines - fuel optimised
-
- Maximum Power
- 74 hp
- 55 kW
- Maximum Torque
- 215 lb-ft @ 1400 rpm
- 291 Nm @ 1400 rpm
- Emissions
- EU Stage II/U.S. EPA Tier 2 equivalent
- EU Stage II/U.S. EPA Tier 2 equivalent
1103C-33T
The 1103 range provides cost effective power solutions and is proving particularly popular with operators of tractors. The engines meet EU Stage II/Stage IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards. The compact 3.3 litre engines have a cylinder head and block design that gives mastery of air control, maintains bore roundness under pressure, and reduces combustion and mechanical noise. High quality oil and fuel filtration deliver improved reliability and durability.
Learn More
The 1103D engines – which deliver 36.9-58 kW (49.5-77.8 hp) at 2200 rpm – are particularly suitable for tractors and compact industrial applications, and have features and benefits that really meet your industrial power applications needs.- Maximum Power
- 49.5 hp
- 36.9 kW
- Maximum Torque
- 139.3 lb-ft @ 1400 rpm
- 189 Nm @ 1400 rpm
- Emissions
- UN ECE R96 Stage IIIA
- UN ECE R96 Stage IIIA
1103D-33
The 1103 range provides cost effective power solutions and is proving particularly popular with operators of tractors. The engines meet EU Stage II/Stage IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards. The compact 3.3 litre engines have a cylinder head and block design that gives mastery of air control, maintains bore roundness under pressure, and reduces combustion and mechanical noise. High quality oil and fuel filtration deliver improved reliability and durability.
Learn More
The 1103D engines – which deliver 36.9-58 kW (49.5-77.8 hp) at 2200 rpm – are particularly suitable for tractors and compact industrial applications, and have features and benefits that really meet your industrial power applications needs.- Maximum Power
- 77.8 hp
- 58 kW
- Maximum Torque
- 228.6 lb-ft @ 1400 rpm
- 310 Nm @ 1400 rpm
- Emissions
- UN ECE R96 Stage IIIA
- UN ECE R96 Stage IIIA
1103D-33TA
The 1103 range provides cost effective power solutions and is proving particularly popular with operators of tractors. The engines meet EU Stage II/Stage IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards. The compact 3.3 litre engines have a cylinder head and block design that gives mastery of air control, maintains bore roundness under pressure, and reduces combustion and mechanical noise. High quality oil and fuel filtration deliver improved reliability and durability.
Learn More
The 1103D engines – which deliver 36.9-58 kW (49.5-77.8 hp) at 2200 rpm – are particularly suitable for tractors and compact industrial applications, and have features and benefits that really meet your industrial power applications needs.- Maximum Power
- 85 hp
- 63.5 kW
- Maximum Torque
- 216 lb-ft @ 1200 rpm
- 293 Nm @ 1200 rpm
- Emissions
- Non-Certified
- Non-Certified
1104A-44
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 85.8 hp
- 64 kW
- Maximum Torque
- 227 lb-ft @ 1200 rpm
- 308 Nm @ 1200 rpm
- Emissions
- EU Stage II/U.S. EPA Tier 2 equivalent
- EU Stage II/U.S. EPA Tier 2 equivalent
1104C-44
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 75 hp
- 55.9 kW
- Maximum Torque
- 195 lb-ft @ 1700 rpm
- 265 Nm @ 1700 rpm
- Emissions
- UN ECE R96 Stage IIIA, China Nonroad Stage III
- UN ECE R96 Stage IIIA, China Nonroad Stage III
1104D-44
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
The 1104 range offers a choice of mechanical or electronically controlled common rail engines that are smooth and quiet in operation.- Maximum Power
- 108 hp
- 80.5 kW
- Maximum Torque
- 298 lb-ft @ 1400 rpm
- 404 Nm @ 1400 rpm
- Emissions
- Non-Certified
- Non-Certified
1104A-44T
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 99.9 hp
- 74.5 kW
- Maximum Torque
- 306 lb-ft @ 1350 rpm
- 415 Nm @ 1350 rpm
- Emissions
- EU Stage II/U.S. EPA Tier 2 equivalent
- EU Stage II/U.S. EPA Tier 2 equivalent
1104C-44T
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 99.9 hp
- 74.5 kW
- Maximum Torque
- 289 lb-ft @ 1400 rpm
- 392 Nm @ 1400 rpm
- Emissions
- UN ECE R96 Stage IIIA, China Nonroad Stage III
- UN ECE R96 Stage IIIA, China Nonroad Stage III
1104D-44T
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 100 hp
- 74.5 kW
- Maximum Torque
- 310 lb-ft @ 1400 rpm
- 420 Nm @ 1400 rpm
- Emissions
- UN ECE R96 Stage IIIA, China Nonroad Stage III
- UN ECE R96 Stage IIIA, China Nonroad Stage III
1104D-E44T
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 130.1 hp
- 97 kW
- Maximum Torque
- 369 lb-ft @ 1400 rpm
- 500 Nm @ 1400 rpm
- Emissions
- EU Stage II/U.S. EPA Tier 2 equivalent
- EU Stage II/U.S. EPA Tier 2 equivalent
1104C-44TA
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 111.3 hp
- 83 kW
- Maximum Torque
- 308 lb-ft @ 1400 rpm
- 418 Nm @ 1400 rpm
- Emissions
- UN ECE R96 Stage IIIA, China Nonroad Stage III
- UN ECE R96 Stage IIIA, China Nonroad Stage III
1104D-44TA
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 142 hp
- 106 kW
- Maximum Torque
- 411.2 lb-ft @ 1400 rpm
- 558 Nm @ 1400 rpm
- Emissions
- UN ECE R96 Stage IIIA, China Nonroad Stage III, Brazil MAR-1
- UN ECE R96 Stage IIIA, China Nonroad Stage III, Brazil MAR-1
1104D-E44TA
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More
Electronic common rail, turbocharged aftercooled engine designed to meet EU Stage IIIA/U.S. EPA Tier 3 equivalent emissions standards for off-road machines- Maximum Power
- 217 hp
- 162 kW
- Maximum Torque
- 663 lb-ft @ 1400 rpm
- 900 Nm @ 1400 rpm
- Emissions
- EU Stage II/U.S. EPA Tier 2 equivalent
- EU Stage II/U.S. EPA Tier 2 equivalent
1106C-70TA
The 1106C provides a common solution to meeting the EU Stage II and U.S. EPA Tier 2 emissions regulations, providing a choice of solutions from the Perkins® 1100 Series diesel engine platform.
Learn More
These clean engines are assembled around optimal, efficient manufacturing processes with state-of-the-art technology. They are built to provide the exact power solution for customers who sell their applications into lesser regulated countries.
The new engines boast considerable increases to delivered power, torque and noise reduction. These have been achieved through changes to the manifold and combustion areas, turbocharger geometry, increased cylinder displacement.
Focusing on our common platform theme, changes to engine envelope dimensions and connection points have been kept to a minimum.- Maximum Power
- 173 hp
- 129 kW
- Maximum Torque
- 553 lb-ft @ 1300 rpm
- 750 Nm @ 1300 rpm
- Emissions
- UN ECE R96 Stage IIIA
- UN ECE R96 Stage IIIA
1106D-70TA
The 6 cylinder option in the Perkins 1100 Series, the 1106 range delivers the power you need for earth moving and construction all the way through to agricultural use and warehousing. Choice of mechanically or electronically controlled engines depending on the power output required and application. With models meeting EU Stage II/Stage III and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the engines form a common platform with our 1200 Series Stage IV/Tier 4 Final engines. This allows for an easy transition when you need to upgrade to the next emissions level.
Learn More- Maximum Power
- 274.9 hp
- 205 kW
- Maximum Torque
- 774.4 lb-ft @ 1400 rpm
- 1050 Nm @ 1400 rpm
- Emissions
- UN ECE R96 Stage IIIA, Brazil MAR-1, China NRIII
- UN ECE R96 Stage IIIA, Brazil MAR-1, China NRIII
1106D-E70TA
The 6 cylinder option in the Perkins 1100 Series, the 1106 range delivers the power you need for earth moving and construction all the way through to agricultural use and warehousing. Choice of mechanically or electronically controlled engines depending on the power output required and application. With models meeting EU Stage II/Stage III and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the engines form a common platform with our 1200 Series Stage IV/Tier 4 Final engines. This allows for an easy transition when you need to upgrade to the next emissions level.
Learn More-
- Maximum Power
- 86 HP
- 64 kW
- Maximum Torque
- 223 lb-ft @ 1400 rpm
- 302 Nm @ 1400 rpm
- Emissions
- EU Stage II/U.S. EPA Tier 2 equivalent
- EU Stage II/U.S. EPA Tier 2 equivalent
1104C-44
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 100 HP
- 74.5 kW
- Maximum Torque
- 304 lb-ft @ 1400 rpm
- 412 Nm @ 1400 rpm
- Emissions
- EU Stage II/U.S. EPA Tier 2 equivalent
- EU Stage II/U.S. EPA Tier 2 equivalent
1104C-44T
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 88.5 HP
- 66 kW
- Maximum Torque
- 289.1 lb-ft @ 1400 rpm
- 392 Nm @ 1400 rpm
- Emissions
- UN ECE R96 Stage IIIA, China Nonroad Stage III
- UN ECE R96 Stage IIIA, China Nonroad Stage III
1104D-44T
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 123.6 HP
- 92.2 kW
- Maximum Torque
- 358 lb-ft @ 1400 rpm
- 485 Nm @ 1400 rpm
- Emissions
- EU Stage II/U.S. EPA Tier 2 equivalent
- EU Stage II/U.S. EPA Tier 2 equivalent
1104C-44TA
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 103.2 HP
- 77 kW
- Maximum Torque
- 308.3 lb-ft @ 1400 rpm
- 418 Nm @ 1400 rpm
- Emissions
- UN ECE R96 Stage IIIA, China Nonroad Stage III
- UN ECE R96 Stage IIIA, China Nonroad Stage III
1104D-44TA
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application,
Learn More- Maximum Power
- 142 HP
- 106 kW
- Maximum Torque
- 410 lb-ft @ 1400 rpm
- 556 Nm @ 1400 rpm
- Emissions
- UN ECE R96 Stage IIIA, China Nonroad Stage III, Brazil MAR-1, China NRIII
- UN ECE R96 Stage IIIA, China Nonroad Stage III, Brazil MAR-1, China NRIII
1104D-E44TA
Whatever your application, there's an 1104 engine for you. Part of the Perkins 1100 Series, the range's 4 cylinder, 4.4 litre engines are smooth and quiet in operation. Designed to meet EU Stage II/IIIA and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the 1104 range offer a choice of mechanical or electronically controlled common rail engines. Electronically controlled engines deliver the right fuel injection for the load applied to the engine. Common front and rear ends, connection points and components across the range, making it easy to install a different 1100 Series engine in your application.
Learn More- Maximum Power
- 275 hp
- 205 kW
- Maximum Torque
- 774 lb-ft @ 1400 rpm
- 1050 Nm @ 1400 rpm
- Emissions
- UN ECE R96 Stage IIIA, Brazil MAR-1, China NRIII
- UN ECE R96 Stage IIIA, Brazil MAR-1, China NRIII
1106D-E70TA
The 6 cylinder option in the Perkins 1100 Series, the 1106 range delivers the power you need for earth moving and construction all the way through to agricultural use and warehousing. Choice of mechanically or electronically controlled engines depending on the power output required and application. With models meeting EU Stage II/Stage III and U.S. EPA Tier 2/Tier 3 equivalent emissions standards, the engines form a common platform with our 1200 Series Stage IV/Tier 4 Final engines. This allows for an easy transition when you need to upgrade to the next emissions level.
