904 Series

Perkins® 904 Series 2.8 litre and 3.6 litre options are built to bring your business success. Offering outstanding power density in a compact package, the range has been designed to integrate perfectly into existing – and future – generations of machine. The engine range meets current and future emission standards worldwide, including EU Stage V, and has the flexibility to adapt to new machine technologies as they evolve.

These 2.8 and 3.6 litre engine platforms from Perkins are designed to provide robust and adaptable power solutions for compact construction, agriculture and industrial machines.

The engine offers OEMs the flexibility to meet different emissions standards – including Stage V, whilst maintaining a common machine design. OEMs will be able to access multiple territories without designing completely different engine installations, thus saving them time and money.

In the design phase, this engine has been specifically tested for fit within the space requirements of major competitor engines in more than 80 different machine applications. With the confidence that this engine can be installed with minimum machine change, OEMs can move to Perkins to get the professional supply partnership that they need.

of

Perkins® 904 Series

Perkins® 904 Series

Perkins® 904 Series engine range

  • 904J-E28T
    Maximum Power
    74 hp
    55 kW
    Maximum Torque
    221 lb-ft @ 1600 rpm
    300 Nm @ 1600 rpm
    Emissions
    EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4
    EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4

    904J-E28T

    The 904 Series engines offer a compact power solution for off-highway applications in construction, agriculture and industrial.

    For our customers these compact, 4 cylinder engines provide excellent performance in power, peak and low speed torque, fuel consumption and transient response.

    Reliability and easy service access are integral to the design of the engines. It is available with a range of installation options to enable OEMs to minimise the size of the engine bay of their machines.

    Learn More
  • 904J-E28TA
    Maximum Power
    74 hp
    55 kW
    Maximum Torque
    280 lb-ft @ 1360 rpm
    380 Nm @ 1360 rpm
    Emissions
    EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4
    EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4

    904J-E28TA

    The 904 Series engines offer a compact power solution for off-highway applications in construction, agriculture and industrial.

    For our customers these compact, 4 cylinder engines provide excellent performance in power, peak and low speed torque, fuel consumption and transient response.

    Reliability and easy service access are integral to the design of the engines. It is available with a range of installation options to enable OEMs to minimise the size of the engine bay of their machines.

    Learn More
  • 904D-E28T
    Maximum Power
    74 hp
    55 kW
    Maximum Torque
    221 lb-ft @ 1600 rpm
    300 Nm @ 1600 rpm
    Emissions
    UN ECE R96 Stage IIIA, Brazil MAR-1
    UN ECE R96 Stage IIIA, Brazil MAR-1

    904D-E28T

    The 904 Series engines offer a compact power solution for off-highway applications in construction, agriculture and industrial.For our customers these compact, 4 cylinder engines provide excellent performance in power, peak and low speed torque, fuel consumption and transient response.Reliability and easy service access are integral to the design of the engines. It is available with a range of installation options to enable OEMs to minimise the size of the engine bay of their machines.

    Learn More
  • 904J-E36TA
    Maximum Power
    134 hp
    100 kW
    Maximum Torque
    406 lb-ft @ 1500 rpm
    550 Nm @ 1500 rpm
    Emissions
    EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4
    EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4

    904J-E36TA

    The 904 Series engines offer a compact power solution for off-highway applications in construction, agriculture and industrial.

    For our customers these compact, 4 cylinder engines provide excellent performance in power, peak and low speed torque, fuel consumption and transient response.

    Reliability and easy service access are integral to the design of the engines. It is available with a range of installation options to enable OEMs to minimise the size of the engine bay of their machines.

    Learn More
  • 904J-E36TA for Tractors
    Maximum Power
    134 hp
    100 kW
    Maximum Torque
    391 lb-ft @ 1500 rpm
    530 Nm @ 1500 rpm
    Emissions
    EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4
    EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4

    904J-E36TA for Tractors

    The 904 Series, 3.6 engine offers the perfect solution for frameless agricultural tractors - compact, powerful and quiet. Compact packaging including structural capability for front bolster and rear transmission, including twin balancers for operator comfort and rigid mounting; the 3.6 is the cornerstone of your tractor.

    Our tight engine packaging combined with our compact aftertreatment is able to be mounted under the tractor bonnet. This enables tight turning circles and uninterrupted sight lines with no A-Pillar or battery box interference; the 904 Series enables less administration and easy logistics for the original equipment manufacturer.

    Powerful, with excellent performance in power, peak and low speed torque, fuel consumption and transient response; the 3.6 has all the performance required including for downsizing from larger displacement engines for your tractor and your customers. A naturally quiet engine by design, your customers will be impressed with the noise and sound quality of the engine, making the 3.6 a natural choice for tractors used around livestock and noise sensitive areas.

    Meets EU Stage V, U.S. EPA Tier 4 Final and Japan MLIT Step 4.

    Learn More
  • 904EA-E36TA
    Maximum Power
    110 hp
    82 kW
    Maximum Torque
    332 lb-ft @ 1500 rpm
    450 Nm @ 1500 rpm
    Emissions
    China NR IV
    China NR IV

    904EA-E36TA

    The 904 Series engines offer a compact power solution for off-highway applications in construction and industrial.

    For our customers these compact, 4 cylinder engines provide excellent performance in power, peak and low speed torque, fuel consumption and transient response.

    Reliability and easy service access are integral to the design of the engines. It is available with a range of installation options to enable OEMs to minimise the size of the engine bay of their machines.

    Learn More
  • 904D-E36TA
    Maximum Power
    121 hp
    90 kW
    Maximum Torque
    369 lb-ft @ 1500 rpm
    500 Nm @ 1500 rpm
    Emissions
    UN ECE R96 Stage IIIA, Brazil MAR-1
    UN ECE R96 Stage IIIA, Brazil MAR-1

    904D-E36TA

    The 904 Series, 3.6 litre offers a compact power solution for off-highway machines in construction, agriculture and industrial.The technology has been chosen not only to meet emissions standards but also to provide excellent performance in power, peak and low speed torque, fuel consumption and transient response.Reliability and easy service access are integral to the design of the 904. It is available with a range of installation options to enable OEMs to minimise the size of the engine bay of their machines.

    Learn More
  • 904D-E36TA for Tractors
    Maximum Power
    121 hp
    90 kW
    Maximum Torque
    369 lb-ft @ 1500 rpm
    500 Nm @ 1500 rpm
    Emissions
    UN ECE R96 Stage IIIA, Brazil MAR-1
    UN ECE R96 Stage IIIA, Brazil MAR-1

    904D-E36TA for Tractors

    The 904 Series, 3.6 engine offers the perfect solution for frameless agricultural tractors - compact, powerful and quiet. Compact packaging including structural capability for front bolster and rear transmission, including twin balancers for operator comfort and rigid mounting; the 3.6 is the cornerstone of your tractor.

    Our compact engine packaging enables tight turning circles and uninterrupted sight lines with no aftertreatment required and no A-Pillar or battery box interference; the 3.6 enables simple integration and easy logistics for the original equipment manufacturer.

    Powerful, with excellent performance in power, peak and low speed torque, fuel consumption and transient response; the 3.6 has all the performance required including for downsizing from larger displacement engines for your tractor and your customers.

    A naturally quiet engine by design, your customers will be impressed with the noise and sound quality of the engine, making the 3.6 a natural choice for tractors used around livestock and noise sensitive areas.

    Learn More
  • 904J-E28T
    Maximum Power
    74 HP
    55 kW
    Maximum Torque
    221 lb-ft @ 1600 rpm
    300 Nm @ 1600 rpm
    Emissions
    EU Stage V/U.S. EPA Tier 4 Final/ Japan 2014 (Tier 4 Final)
    EU Stage V/U.S. EPA Tier 4 Final/ Japan 2014 (Tier 4 Final)

    904J-E28T

    The Perkins® 904Series IOPU gives you a complete power solution to meet EU Stage V, U.S. EPA Tier 4 Final and Japan 2014 (Tier 4 Final) emission standards. The choice of options, engine configurations and robust technology allows you to integrate the 904 range into your equipment with minimum re-engineering

    Learn More
  • 904J-E36TA
    Maximum Power
    134 HP
    100 kW
    Maximum Torque
    406 lb-ft @ 1500 rpm
    550 Nm @ 1500 rpm
    Emissions
    EU Stage V/U.S. EPA Tier 4 Final/ Japan 2014 (Tier 4 Final)
    EU Stage V/U.S. EPA Tier 4 Final/ Japan 2014 (Tier 4 Final)

    904J-E36TA

    The Perkins® 904Series IOPU gives you a complete power solution to meet EU Stage V, U.S. EPA Tier 4 Final and Japan 2014 (Tier 4 Final) emission standards. The choice of options, engine configurations and robust technology allows you to integrate the 904 range into your equipment with minimum re-engineering

    Learn More

Enhanced performance

The 4 cylinder 2.8 litre 904J-E28TA provides a maximum of 55 kW (74 hp) with torque of up to 380 Nm. The 3.6 litre 904J-E36TA option delivers 100 kW (134 hp) and up to 550 Nm of torque.

The high power and torque density will give OEMs who are looking to move to smaller, more compact engines, and the great fuel consumption, fast response and electronic integration to differentiate their machines.

Extreme reliability

Reliability is critical to your reputation – and ours. As an off-highway engine specialist, we validate the technologies we use in our engines for heavy duty work in harsh environments. We use extensive predictive engineering, which we back up with one of the most complete physical field test programs in our industry.

We also understand that fast and responsive aftersales is vital to maintaining customer loyalty. And we’re here to support you with easy access to a full suite of genuine parts, training and documentation from day one.
