1200 Series
The 1200 Series industrial and electric power engines are designed to operate around the clock, in whatever environmental conditions you choose. They are packed with the latest technology—delivering reduced complexity and cost—whilst also providing the opportunity to downsize and improve productivity. The 1200J products meet EU Stage V/U.S. EPA Tier 4 Final emission standards.
Perkins® 1200 Series engine range
Industrial engines
Industrial open power units
Electric power engines - certified
Electric power engines - fuel optimised
-
- Maximum Power
- 148 HP
- 110 kW
- Maximum Torque
- 413 lb-ft @ 1400 rpm
- 560 Nm @ 1400 rpm
- Emissions
- China NR IV
- China NR IV
1204EA-E44TA
The Perkins 1204, the 4 cylinder option for the 1200 Series, gives you a complete power solution that meets the latest China NR IV emission standards. The choice of options, engine configurations and robust technology allows you to integrate the 1204 range into your equipment with minimum re-engineering.
Learn More
The innovative, compact and flexible design of the Perkins 1200 Series means it can be found in more than 800 different models of equipment. -
- Maximum Power
- 147.6 HP
- 110.1 kW
- Maximum Torque
- 413 lb-ft @ 1400 rpm
- 560 Nm @ 1400 rpm
- Emissions
- U.S. EPA & CARB Tier 4 Final
- U.S. EPA & CARB Tier 4 Final
1204F-E44TA
The Perkins 1204F, the 4 cylinder option for the 1200 Series, gives you a complete power solution that meets the latest EU Stage IV/U.S. EPA Tier 4 Final emission standards. The choice of options, engine configurations and robust technology allows you to integrate the 1204 range into your equipment with minimum re-engineering.
Learn More
The innovative, compact and flexible design of the Perkins 1200 Series means it can be found in more than 800 different models of equipment. -
- Maximum Power
- 148 HP
- 110 kW
- Maximum Torque
- 413 lb-ft @ 1400 rpm
- 560 Nm @ 1400 rpm
- Emissions
- EU Stage V, U.S. EPA & CARB Tier 4 Final
- EU Stage V, U.S. EPA & CARB Tier 4 Final
1204J-E44TA
The Perkins 1204J, the 4 cylinder option for the 1200 Series, gives you a complete power solution that meets EU Stage V / U.S. Tier 4 Final emissions standards. The choice of options, engine configurations and robust technology allows you to integrate the 1204 range into your equipment with minimum re-engineering.
Learn More
The innovative, compact and flexible design of the Perkins 1200 Series means it can be found in more than 800 different models of equipment. -
- Maximum Power
- 173 HP
- 129 kW
- Maximum Torque
- 553 lb-ft @ 1400 rpm
- 750 Nm @ 1400 rpm
- Emissions
- China NR IV
- China NR IV
1204EA-E44TTA
The Perkins 1204, the 4 cylinder option for the 1200 Series TM, gives you a complete power solution that meets the latest China NR IV emission standards. The choice of options, engine configurations and robust technology allows you to integrate the 1204 range into your equipment with minimum re-engineering.
Learn More
The innovative, compact and flexible design of the Perkins 1200 Series means it can be found in more than 800 different models of equipment. -
- Maximum Power
- 173.5 HP
- 129.4 kW
- Maximum Torque
- 553.1 lb-ft @ 1400 rpm
- 750 Nm @ 1400 rpm
- Emissions
- U.S. EPA & CARB Tier 4 Final
- U.S. EPA & CARB Tier 4 Final
1204F-E44TTA
The Perkins 1204F, the 4 cylinder option for the 1200 Series, gives you a complete power solution that meets the latest EU Stage IV/U.S. EPA Tier 4 Final emission standards. The choice of options, engine configurations and robust technology allows you to integrate the 1204 range into your equipment with minimum re-engineering.
Learn More
The innovative, compact and flexible design of the Perkins 1200 Series means it can be found in more than 800 different models of equipment. -
- Maximum Power
- 200 HP
- 150 kW
- Maximum Torque
- 609 lb-ft @ 1400 rpm
- 825 Nm @ 1400 rpm
- Emissions
- EU Stage V, U.S. EPA Tier 4 Final
- EU Stage V, U.S. EPA Tier 4 Final
1204J-E44TTA
The Perkins 1204J, the 4 cylinder option for the 1200 Series, gives you a complete power solution that is EU Stage V / U.S Tier 4 Final. The choice of options, engine configurations and robust technology allows you to integrate the 1204 range into your equipment with minimum re-engineering.
Learn More
The innovative, compact and flexible design of the Perkins 1200 Series means it can be found in more than 800 different models of equipment. -
- Maximum Power
- 202 HP
- 151 kW
- Maximum Torque
- 642 lb-ft @ 1400 rpm
- 870 Nm @ 1400 rpm
- Emissions
- China NR IV
- China NR IV
1206EA-E70TA
The 6 cylinder option for the Perkins 1200 Series, the 1206 gives you a complete power solution that meets China NR IV emission standards. The choice of options, engine configurations and robust technology allows you to integrate the 1206 range into your equipment with minimum re-engineering.1206EA-E70TA INDUSTRIAL ENGINE7.0 litre129-151 kW (174-202 hp)China NR IV emission standards.
Learn More -
- Maximum Power
- 202 HP
- 151 kW
- Maximum Torque
- 642 lb-ft @ 1400 rpm
- 870 Nm @ 1400 rpm
- Emissions
- EU Stage V, U.S Tier 4 Final
- EU Stage V, U.S Tier 4 Final
1206J-E70TA
The 6 cylinder option for the Perkins 1200 Series, the 1206J gives you a complete power solution that is EU Stage V / U.S. EPA Tier 4 Final. The choice of options, engine configurations and robust technology allows you to integrate the 1206 range into your equipment with minimum re-engineering.
Learn More -
- Maximum Power
- 302 HP
- 225 kW
- Maximum Torque
- 940 lb-ft @ 1400 rpm
- 1274 Nm @ 1400 rpm
- Emissions
- China NR IV
- China NR IV
1206EA-E70TTA
The 6 cylinder option for the Perkins 1200 Series, the 1206 gives you a complete power solution that meets China NR IV emission standards. The choice of options, engine configurations and robust technology allows you to integrate the 1206 range into your equipment with minimum re-engineering.
Learn More -
- Maximum Power
- 320 HP
- 239 kW
- Maximum Torque
- 935 lb-ft @ 1400 rpm
- 1282 Nm @ 1400 rpm
- Emissions
- EU Stage V, U.S. EPA & CARB Tier 4 Final
- EU Stage V, U.S. EPA & CARB Tier 4 Final
1206J-E70TTA
The 6 cylinder option for the Perkins 1200 Series, the 1206J gives you a complete power solution that is EU Stage V - ready. The choice of options, engine configurations and robust technology allows you to integrate the 1206 range into your equipment with minimum re-engineering.
Learn More
-
- Maximum Power
- 147 HP
- 110.1 kW
- Maximum Torque
- 413 lb-ft @ 1400 rpm
- 560 Nm @ 1400 rpm
- Emissions
- EU Stage IIIB/U.S. EPA Tier 4 Interim equivalent
- EU Stage IIIB/U.S. EPA Tier 4 Interim equivalent
1204E-E44TA
Learn More -
- Maximum Power
- 147.5 HP
- 110.1 kW
- Maximum Torque
- 413 lb-ft @ 1400 rpm
- 560 Nm @ 1400 rpm
- Emissions
- U.S. EPA & CARB Tier 4 Final
- U.S. EPA & CARB Tier 4 Final
1204F-E44TA
Learn More -
- Maximum Power
- 147.6 HP
- 110 kW
- Maximum Torque
- 413 lb-ft @ 1400 rpm
- 560 Nm @ 1400 rpm
- Emissions
- EU Stage V, U.S. EPA Tier 4 Final
- EU Stage V, U.S. EPA Tier 4 Final
1204J-E44TA
Learn More -
- Maximum Power
- 173.5 HP
- 129.4 kW
- Maximum Torque
- 553.2 lb-ft @ 1400 rpm
- 750 Nm @ 1400 rpm
- Emissions
- U.S. EPA & CARB Tier 4 Final
- U.S. EPA & CARB Tier 4 Final
1204F-E44TTA
Learn More -
- Maximum Power
- 190 HP
- 139.8 kW
- Maximum Torque
- 601 lb-ft @ 1400 rpm
- 815 Nm @ 1400 rpm
- Emissions
- EU Stage V, U.S. EPA Tier 4 Final
- EU Stage V, U.S. EPA Tier 4 Final
1204J-E44TTA
Learn More -
- Maximum Power
- 300 BHP
- 225 kW
- Maximum Torque
- 940 lb-ft @ 1400 rpm
- 1274 Nm @ 1400 rpm
- Emissions
- EU Stage V, U.S. EPA Tier 4 Final
- EU Stage V, U.S. EPA Tier 4 Final
1206J-E70TTA
Learn More
-
- Gross Mechanical Output
- 114-129 kWm
- 114-129 kWm
- Typical Electrical Output
- 120.0-132 kVA (91.0-100 kWe)
- 120.0-132 kVA (91.0-100 kWe)
- Emissions
- EU Stage V, U.S. EPA Tier 4 Final
- EU Stage V, U.S. EPA Tier 4 Final
1204J-E44TTAG
Perkins 1200 Series electric power engines deliver the power you need, when you need it. From hospitals to hotels, icy wastelands to scorching deserts, construction sites to factories our engines provide the reliability, low operating costs and exceptional performance you need. Engines range from 4.4 to 7 litre, are turbocharged and chargecooled for extra power and load acceptance, while meeting the latest stringent emissions standards.
Learn More -
- Gross Mechanical Output
- 186 -248.5 kWm
- 186 -248.5 kWm
- Typical Electrical Output
- 200-275 kVA (160-220 kWe)
- 200-275 kVA (160-220 kWe)
- Emissions
- EU Stage IIIA
- EU Stage IIIA
1206D-E70TTAG
Perkins is pleased to announce the natural expansion of the 1200 Series to include a new addition to the ElectropaK range.
Learn More
The whole engine has been built around the demands of our customers and as such offers a great package with a simple integration design.
Perkins have developed a reputation for designing and building reliable and durable engines suitable for the most demanding applications. -
- Gross Mechanical Output
- 182-239 kWm
- 182-239 kWm
- Typical Electrical Output
- 200-220 kVA (135-200 kWe)
- 200-220 kVA (135-200 kWe)
- Emissions
- EU Stage V, U.S. EPA Tier 4 Final
- EU Stage V, U.S. EPA Tier 4 Final
1206J-E70TTAG
Perkins 1200 Series electric power engines deliver the power you need, when you need it. From hospitals to hotels, icy wastelands to scorching deserts, construction sites to factories our engines provide the reliability, low operating costs and exceptional performance you need. Engines range from 4.4 to 7 litre, are turbocharged and chargecooled for extra power and load acceptance, while meeting the latest stringent emissions standards.
Learn More
-
