Total Power Range
| Gross Mechanical Output | 8.6-9.5 kWm 8.6-9.5 kWm |
| Typical Electrical Output | 9.0-10 kVA (7.2-8 kWe) 9.0-10 kVA (7.2-8 kWe) |
| Rated Speed | 1500 rpm 1500 rpm |
Electric Power Generation 403J-11G
Request Consultation Find your DistributorKey Specs
- Gross Mechanical Output
- 8.6-9.5 kWm
- 8.6-9.5 kWm
- Typical Electrical Output
- 9.0-10 kVA (7.2-8 kWe)
- 9.0-10 kVA (7.2-8 kWe)
- Emissions
- EU Stage V
- EU Stage V
Overview
The Perkins® 400 Series engine family continues to set new standards in the compact engine market. Developed alongside customers to fulfil their needs in the generator set market, they have been designed to comply with stringent emissions regulations for EU and USA. The 403 Product range offers a highly compact Perkins electro units and electropaKs to provide robust 3 cylinder diesel engines designed to provide economic and durable operation for prime power applications, hitting the key power nodes required by the power generation industry.
Features At A Glance
GB/aftermarket/perkins-platinum-protection.
Product Specifications for 403J-11G
Emission Standards
| Emissions | EU Stage V EU Stage V |
50 Hz Typical Electrical Output
| Prime | 9 kVA 9 kVA |
| Standby | 10 kVA 10 kVA |
General
| Number of Cylinders | 3 inline 3 inline |
| Bore | 3 in 77 mm |
| Stroke | 3.2 in 81 mm |
| Displacement | 69 in³ 1.1 l |
| Compression Ratio | 23.0:1 23.0:1 |
| Aspiration | Naturally aspirated Naturally aspirated |
| Combustion System | Mechanical indirect injection Mechanical indirect injection |
| Rotation from Flywheel End | Anti-clockwise Anti-clockwise |
| Cooling System | Watercooled Watercooled |
| Aftertreatment | - - |
| Typical Alternator Efficiency | 86% 86% |
| Switchable | No No |
ElectropaK Dimensions
| Length | 30.6 in 776 mm |
| Width | 17.7 in 449 mm |
| Height | 27.6 in 700 mm |
| Dry Weight | 284 lb 129 kg |
Disclaimer
| Note 1 | *Final dimensions dependent on selected options *Final dimensions dependent on selected options |
Definitions
| Prime Power | Unlimited hours usage with an average load factor of 80% of the published prime power over each 24 hour period. A 10% overload is available for 1 hour in every 12 hours operation. Unlimited hours usage with an average load factor of 80% of the published prime power over each 24 hour period. A 10% overload is available for 1 hour in every 12 hours operation. |
| Standby Power | Limited to 500 hours annual usage with an average load factor of 80% of the published standby power rating over each 24 hour period. Up to 300 hours of annual usage may be run continuously. No overload is permitted on standby power. Limited to 500 hours annual usage with an average load factor of 80% of the published standby power rating over each 24 hour period. Up to 300 hours of annual usage may be run continuously. No overload is permitted on standby power. |
403J-11G Standard Equipment
Electro unit
Fuel filter, engine mounted
Fuel priming pump (manual)
Air filter, engine mounted
Starter motor
Battery charging alternator
Flywheel housing
Flywheel
Fan
Fan guard
Temperature and oil pressure for automatic stop/alarm configurable
