6 Cylinder
The 1700 Series of engines takes Perkins industrial offering into a new power bracket, giving original equipment manufacturers (OEMs) the opportunity to extend the use of our engines across their range. The series offers excellent power density, allowing customers to downsize and save money, low cost of installation and ownership, and robust and reliable performance. Packed with advanced engine technologies, the series is designed to meet U.S. EPA Tier 4 Final emissions standards – and is also EU Stage V capable.
Perkins® 1700 Series is a powerful, compact and robust family of industrial engines designed to improve the performance and productivity of your machines. Engines in the series meet Tier 4 Final emission standards and are designed to meet Stage V – meaning they’re designed with the future in mind.
The 6 cylinder 1706 model is a 9.3 litre turbocharged and aftercooled unit with direct injection and a fully electronic control system. With a power range of 250-340 kW (335-456 hp) it’s the ideal choice for hard-working applications, particularly in construction, and has been validated to deliver optimal performance in the harshest working environments.
The new 1700 Series
Perkins® 1700 Series engine range
-
- Maximum Power
- 416 hp
- 310 kW
- Maximum Torque
- 1335 lb-ft @ 1400 rpm
- 1810 Nm @ 1400 rpm
- Emissions
- China Nonroad Stage III, Brazil MAR-1, UN ECE R96 Stage IIIA
- China Nonroad Stage III, Brazil MAR-1, UN ECE R96 Stage IIIA
1706D-E93TA
The Perkins® 1706D-E93TA is a 6 cylinder, 9.3 litre engine that produces up to 310 kW (416 hp) of power and 1810 Nm (1335 lb-ft) of torque out of a compact, lightweight package. The 1706D model is a platform extension of the 1706J and meets China Nonroad Stage III, Brazil MAR-1, and UN R96 Stage IIIA emission standards and UN R120 performance standard for measurement of net power and specific fuel consumption.
Learn More- Maximum Power
- 416 hp
- 310 kW
- Maximum Torque
- 1335 lb-ft @ 1400 rpm
- 1810 Nm @ 1400 rpm
- Emissions
- China Nonroad Stage III, Brazil MAR-1, UN ECE R96 Stage IIIA
- China Nonroad Stage III, Brazil MAR-1, UN ECE R96 Stage IIIA
1706D-E93TA
The Perkins® 1706D-E93TA IOPU provides a complete plug-and-play power solution to meet China Nonroad Stage III, Brazil MAR-1, and UN R96 Stage IIIA emission standards and UN R120 performance standard for measurement of net power and specific fuel consumption. The IOPU configurations come equipped with engine-mounted air filter design, an integrated cooling pack, and full wire harnessing coupled to a single engine-mounted ECM.
Learn More- Maximum Power
- 456 hp
- 340 kW
- Maximum Torque
- 1540 lb-ft @ 1400 rpm
- 2088 Nm @ 1400 rpm
- Emissions
- China Nonroad Stage IV
- China Nonroad Stage IV
1706EA-E93TA
The 1706J/EA-E93TA is a 6 cylinder, 9.3 litre engine that combines a high-pressure common rail fuel system and patented aftertreatment technology to produce up to 340 kW (456 hp) of power and 2088 Nm (1540 lb-ft) of torque out of a compact, lightweight package. The 1706J-E93TA is certified to EU StageV/U.S. EPA Tier 4 Final, and other equivalent certifications. The 1706EA-E93TA is certified to China Nonroad (NR) Stage IV. Identical performance across these certifications provides global customers a single source solution, streamlining design, installation, and service processes.
Learn More- Maximum Power
- 456 hp
- 340 kW
- Maximum Torque
- 1540 lb-ft @ 1400 rpm
- 2088 Nm @ 1400 rpm
- Emissions
- China NRIV
- China NRIV
1706EA-E93TA
The Perkins® 1706J/EA-E93TA IOPU provides a complete plug-and-play power solution to meet EU Stage V, U.S. EPA Tier 4 Final, and other equivalent emissions standards. The 1706EA-E93TA IOPU meets China Nonroad Stage IV emissions standards. The IOPU configurations come equipped with compact technology engine-mounted aftertreatment design, an integrated cooling pack, and full wire harnessing coupled to a single engine-mounted ECM.
Learn More- Maximum Power
- 456 hp
- 340 kW
- Maximum Torque
- 1540 lb-ft @ 1400 rpm
- 2088 Nm @ 1400 rpm
- Emissions
- EU Stage V, U.S. EPA Tier 4 Final, Korea Stage V, Japan 2014
- EU Stage V, U.S. EPA Tier 4 Final, Korea Stage V, Japan 2014
1706J-E93TA
The 1706J/EA-E93TA is a 6 cylinder, 9.3 litre engine that combines a high-pressure common rail fuel system and patented aftertreatment technology to produce up to 340 kW (456 hp) of power and 2088 Nm (1540 lb-ft) of torque out of a compact, lightweight package. The 1706J-E93TA is certified to EU StageV/U.S. EPA Tier 4 Final, and other equivalent certifications. The 1706EA-E93TA is certified to China Nonroad (NR) Stage IV. Identical performance across these certifications provides global customers a single source solution, streamlining design, installation, and service processes.
Learn More- Maximum Power
- 456 hp
- 340 kW
- Maximum Torque
- 1540 lb-ft @ 1400 rpm
- 2088 Nm @ 1400 rpm
- Emissions
- EU Stage V, U.S. EPA Tier 4 Final, Japan 2014, Korea Stage V
- EU Stage V, U.S. EPA Tier 4 Final, Japan 2014, Korea Stage V
1706J-E93TA
The Perkins® 1706J/EA-E93TA IOPU provides a complete plug-and-play power solution to meet EU Stage V, U.S. EPA Tier 4 Final, and other equivalent emissions standards. The 1706EA-E93TA IOPU meets China Nonroad Stage IV emissions standards. The IOPU configurations come equipped with compact technology engine-mounted aftertreatment design, an integrated cooling pack, and full wire harnessing coupled to a single engine-mounted ECM.
Learn MoreExcellent power density
The 9.3 litre 1706 is a new platform for Perkins, which means OEMs can extend the use of our engines across their range. Excellent power density also allows you to select a smaller engine where you might have used a larger unit previously. This downsizing not only creates additional space to optimise your machine installation for operator usability, but it also reduces running costs, making your machines more competitive.
The 1706 has been designed with simple and low-cost installation in mind. Low heat rejection in the engine allows for a small cooling pack, which not only makes it easier to install, it means you’ll spend less on your cooling pack. Features such as on-engine aftertreatment mounting also contribute to reduced installation costs.
Robust performance
This reliable and robust engine has been designed to keep hard-working, productive machines running in the toughest conditions - and ensure they’re as productive as possible.
You can also rely on low cost of ownership, with fuel consumption optimised for a wide range of equipment and applications. Low cost maintenance is also achieved through service-free aftertreatment and 500-hour oil change intervals.
Meeting your global engine needs
The 1706, along with the 13 litre 2206, 15 litre 2506 and 18 litre 2806, expands Perkins industrial engine offering. This saves OEMs time and money by enabling you to go to just one supplier to meet all your engine needs for your global machine line-up.
-
